EFS4WD
Reference: 37-6212
Shocks
EFS XTR Front Strut, 40 mm Lift — Toyota Hilux from 2022 Wide Body, Rogue, GR Sport
EFS XTR MacPherson front strut for the Toyota Hilux from 2022 in Wide Body, Rogue and GR Sport trims, designed for a 40 mm lift. Strut top cap and fitting kit included. 620 x 493 mm, 64 mm body. Five-year warranty with no mileage limit.
EFS XTR Front Strut, 40 mm Lift — Toyota Hilux from 2022 Wide Body, Rogue, GR Sport
A Hilux in Wide Body, Rogue or GR Sport trim looks ready for the terrain straight off the lot, but its suspension is tuned for moderate, predictable use. Add a bumper, a winch and heavier tyres and the front starts working at the end of its travel.
37-6212 is a complete XTR front strut for a 40 mm lift, supplied with the top cap and a fitting kit. Dimensions of 620 x 493 mm and a 64 mm body provide the reserve the factory strut does not have.
Lift 40 mm (2") | Dimensions 620 x 493 mm | Included Top cap and fitting kit |
Key benefits
- A strut calculated for a 40 mm lift returns the working range the lift takes away.
- The top cap and fitting kit are supplied, shortening the job and removing the need to reuse worn parts.
- The 64 mm body carries plenty of oil, so damping fades less over a long gravel stage.
- A 40 mm piston gives control over a front end carrying equipment, including under braking on loose surfaces.
- 2 mm walls in both tubes resist stone strikes and working at an angle.
- DMC-T valving adapts damping to the surface within a hundredth of a second, with no switch involved.
What is in the box
- EFS XTR strut (1 unit)
- Strut top cap
- Fitting kit
Technical data
- Type: MacPherson front strut, EFS XTR series
- Lift: 40 mm (2")
- Dimensions: 620 x 493 mm
- Twin-tube construction
- Outer body diameter: 64 mm
- Piston: 40 mm
- Piston rod: hardened chrome, 20 mm diameter
- Inner and outer wall thickness: 2 mm
- Charge: low-pressure nitrogen
- Valving: DMC-T (Dynamic Motion Control Technology)
- Warranty: 5 years, unlimited kilometres
- Weight: 5.1 kg (EFS manufacturer data)
- Packaging: 80 x 13 x 13 cm (EFS manufacturer data)
- Quantity: 2 per axle
- Application: Toyota Hilux from 2022 in Wide Body, Rogue and GR Sport trims
- Part number: 37-6212
- EAN: 5905247917218
This is for the newest wide-body Hilux, built either for touring or for daily work with a load. Check your trim before ordering — the manufacturer specifies Wide Body, Rogue and GR Sport.
Fitting and notes
Two struts are needed for the front axle. The manufacturer highlights one detail: the helix, the step on the spring seat, must be timed so it faces the rear of the vehicle — a mis-oriented seat changes how the spring sits. The spring is transferred onto the new strut under a compressor, and the alignment needs checking afterwards.
Why it is worth it
- A finished strut with a top cap, not a bare damper you still have to complete.
- Valving matched to a loaded, lifted new-generation Hilux.
- Five years of warranty with no kilometre limit.
If you are building a Wide Body Hilux for real loads, start with a pair of these struts.
Frequently Asked Questions
Which Hilux versions does 37-6212 fit?
The Toyota Hilux from 2022 in Wide Body, Rogue and GR Sport trims.
Do I need to buy a top mount separately?
No. The manufacturer states that the strut top cap and fitting kit are included.
Is there anything specific to watch during fitting?
Yes. The manufacturer notes that the helix, the step on the spring seat, must be timed to face the rear of the vehicle.
What lift is this strut designed for?
A 40 mm lift, which the manufacturer designates as 2 inches.
What warranty applies?
Five years with no kilometre limit.
