WARN R60-S
This product has no reviews yet — write the first one
zł2,105.69
Tax included
WARN R60-S is a 12 V electric winch with a 6,000 lb rated pulling capacity, designed for large UTVs, smaller off-road vehicles, and SUVs. It features a 50 ft synthetic rope, hawse fairlead, all-metal planetary gearing, and IP67 sealing.
WARN R60-S 6,000 lb Synthetic Rope Winch – for UTVs, Small Off-Road Vehicles and SUVs
The WARN R60-S is a compact 12 V electric winch with a rated pulling capacity of 6,000 lb. It is designed for large UTVs as well as smaller pickups, SUVs, and off-road vehicles.
The winch uses synthetic rope, a three-stage planetary gear train, and an automatic load-holding brake. Its IP67 rating helps protect the internal mechanism against water, dust, and trail debris.
Rated Pulling Capacity
6,000 lb
Rope
Synthetic, 50 ft × 1/4 in
Ingress Protection
IP67
Part Number
110060
WARN R60-S Winch
Key Benefits
- 6,000 lb pulling capacity makes the winch suitable for large UTVs and smaller off-road vehicles and SUVs.
- Synthetic rope is lightweight and easier to handle when preparing a recovery line.
- IP67 sealing helps protect the mechanism from water, dust, and dirt encountered off-road.
- All-metal planetary gearing is designed for durability and efficient power transfer under load.
- Automatic brake helps control the rope and hold the load securely.
- Wired remote and dash-mounted switch provide two convenient ways to operate the winch.
- Compact housing helps simplify installation on a compatible winch plate or bumper.
Compact R60-S Design
What Is Included
- WARN R60-S 12 V electric winch,
- 50 ft long, 1/4 in diameter synthetic rope,
- hawse fairlead,
- wired remote control,
- dash-mounted control switch.
Technical Data / Facts
- Type: electric winch
- Voltage: 12 V
- Rated pulling capacity: 6,000 lb
- Motor: permanent magnet
- Gear train: three-stage planetary, all-metal
- Brake: automatic, spring-applied
- Free-spooling: yes
- Mechanical rope payout: yes
- Rope material: synthetic rope
- Rope length: 50 ft
- Rope diameter: 1/4 in
- Fairlead: hawse
- Winch length: 14.1 in
- Maximum height: 4.7 in
- Maximum width: 4.6 in
- Mounting bolt pattern: 6.59 × 3 in
- Number of mounting holes: 4
- Mounting type: fixed mount
- Controls: wired remote and vehicle-mounted switch
- Ingress protection rating: IP67
- D-shackle included: no
- Mechanical warranty: 5 years
- Electrical warranty: 3 years
Recommended Use
- large UTVs,
- smaller pickups and SUVs,
- vehicles used for off-road driving,
- self-recovery from mud, ruts, and soft ground,
- users looking for a WARN 6,000 lb winch with synthetic rope.
WARN R60-S Installed on a UTV
Installation / Notes
- The winch requires a compatible mounting plate or a winch-ready bumper.
- Before installation, check the available space, mounting bolt pattern, and load capacity of the mounting structure.
- The unit uses four mounting holes in a 6.59 × 3 in pattern.
- Wiring, circuit protection, and cable routing should follow the manufacturer’s installation instructions.
Summary for Quick Reference
- Model: WARN R60-S
- Part number: 110060
- Pulling capacity: 6,000 lb
- Power supply: 12 V
- Rope: 50 ft × 1/4 in synthetic rope
- Gear train: three-stage all-metal planetary
- Protection: IP67
- Application: large UTVs, small pickups, SUVs, and off-road vehicles
- Installation: compatible mounting plate or bumper required
