Winch mount kit for the ARB Summit MKII bar – Land Cruiser 70, 76, 78

The Summit MKII bar is winch ready, but being ready is not the same as having a mount. Without the dedicated kit there is nothing for the winch to bolt to – and improvising here ends with the mount tearing out on the first serious pull.

Key features

• Made for the ARB Summit MKII bar on the Land Cruiser 70, 76 and 78 from 2024 – not a universal plate to adapt.
• Covers Warn, Smittybilt and Bushranger winches – the full model list is in the fitment section below.
• A solid mount that carries the load into the bar structure rather than into the skin panels.

Fitment

The kit is for the ARB Summit MKII bar (ARB-3412760) on the Toyota Land Cruiser 70, 76 and 78 from 2024.

Winches covered by this kit, per the manufacturer's chart:

• Warn M8000, XD9000, 9.5XP, 9.5XDC – the XDC also needs ARB-3500410.
• Warn ZEON 8, 8-S, 10, 10-S, 12, 12-S – also needs the W89965 extension kit.
• Warn ZEON Platinum 10, 10-S, 12, 12-S – also W89965; ARB-3500600 spacers if required.
• Warn VR EVO 8, 8-S, 10, 10-S, 12, 12-S – also needs the W106928 extension kit.
• Smittybilt Gen2 X20 10K – also needs the ARB-3500770 adapter kit.
• Bushranger Covert and Revo 10-S, 10-W, 12-S, 12-W.

For most of these the manufacturer lists optional ARB-3500605 spacers where required. Send us your winch model and we will put together exactly what you need, rather than shipping a kit that is one part short.

Specifications

• Part number: 3512150
• Brand: ARB
• For: ARB Summit MKII bar (3412760)
• Vehicle: Toyota Land Cruiser 70, 76, 78 from 2024
• Winch-dependent supplementary kits: W89965, W106928, ARB-3500410, ARB-3500770
• Optional spacers: ARB-3500605 or ARB-3500600

Szekla4x4.pl is an online shop, a walk-in store and a workshop specialising in off-road and overlanding. If you would like us to fit this for you or match the rest of the setup, get in touch.

Frequently asked questions

Is this kit enough to mount my winch?

For some models yes, for others an extension kit or adapter is also needed – the list is in the fitment section. Send us the winch model and we will check.

Does it fit other ARB bars?

No. This part number is for the Summit MKII bar on the Land Cruiser 70, 76 and 78 from 2024.

Is a winch included?

No. This is the mount only.

Why buy it

• The winch bolts to the bar structure, not to an improvised plate.
• The manufacturer's compatibility chart lets the set be assembled correctly first time.
