LED Tail Lights with Horizontal Light Bars - Jeep Wrangler JK/JKU 2007+
A pair of LED tail lights, left and right, for the Jeep Wrangler JK and JKU from the 2007 model year. The supplier states a European version, 12 V DC and IP68 sealing, and describes fitting as replacing the original lamps with no modification. In the photos each lamp has five horizontal light bars and a vertical red element at the edge. The supplier states no type approval.
LED Tail Lights with Horizontal Light Bars - Jeep Wrangler JK/JKU 2007+
A pair of LED tail lights, left and right, for the Jeep Wrangler JK and JKU from the 2007 model year. The supplier states a European version set up for right-hand traffic, 12 V DC supply and IP68 sealing, and puts fitting briefly: replace the original lamps, no modification.
The photos show how the lamp is built: a dark housing with five horizontal light bars and a lower panel in the main section, plus a vertical red element at the outer edge which stays unlit in the photo with the lights on. On the working lamp the upper bars glow white and red while the lower ones glow amber. Which light serves which function, the supplier does not list.
Model Jeep Wrangler JK/JKU from 2007 | Supply 12 V DC | Sealing IP68 per the supplier |
Key features
- Swap with no modification - fitting means removing the original lamps.
- European version - set up for right-hand traffic.
- IP68 sealing - a supplier declaration, and it matters when wading.
Technical data
- Part number: TXJK 145
- Application: Jeep Wrangler JK and JKU from 2007
- The supplier does not list the function of the individual lights
- The supplier states no type approval, connector type, dimensions or weight
Fitting and notes
This is exterior lighting, and the supplier states no E or ECE type approval for it - that has to be settled before registration or a roadworthiness test. Write to us and we will ask before you order. The second matter is the functions: for the sister model TXJK 111 the supplier lists brake, indicator and reversing; for this set it does not. The 5 kg figure on the listing is the distributor's shipping weight.
Frequently asked questions
How does it differ from TXJK 111?
In the light signature: TXJK 111 has a sequential indicator and listed functions, while this set has horizontal light bars and no function list from the supplier.
Is there a type approval?
The supplier states none. With tail lights that is the question a tester will ask.
Does fitting need modification?
The supplier states it replaces the original lamps. The connector type is not specified.
