KC HiLiTES Gravity Titan 50" Light Kit — Jeep Wrangler JK 2007–2017

This is the Gravity Titan 50" kit prepared for the 2007–2017 Jeep Wrangler JK. The bar itself is the same as in the other versions of this kit — what differs is the mounting: dedicated overhead brackets (driver and passenger side) that fit the 2007–2017 Wrangler JK, plus extended mounting bolts.

The kit also contains two ditch-light brackets, fitted only if you want side lights. The photo shows a pair of black formed brackets cut to follow the body line, the eight-light bar and a set of KC covers.

What you get

• Gravity Titan 50" bar with eight lights
• Eight light covers, black with the yellow KC logo
• Plug-N-Play harness with fuse, relay and an illuminated switch
• Pair of overhead brackets for the vehicles listed, plus extended mounting bolts
• Pair of ditch-light brackets (optional to fit)

Gravity Titan 50" bar specification

• Beam pattern: combo
• Output: 2972 lm per light, 23,776 lm total
• Beam distance: 1010 m
• Power: 39 W per light, 316 W total
• Current draw: 26.32 A total
• Voltage: 9–36 V
• Colour: 5000 K, white and amber light
• Bar dimensions: 51.58 x 6.05 x 3.27 in
• Ingress protection: IP68
• SAE/ECE approval: none (per supplier data)

Fitting and notes

The bar goes above the windscreen on brackets bolted by the A-pillars — a two-person job. The supplier states SAE/ECE: none, so before registration and technical inspection you must establish whether and how this lighting may be used on public roads. At 26.32 A, check your alternator can carry it.

Frequently asked questions

Does it fit a Wrangler JL?

No. The supplier lists this version as fitting the Wrangler JK from 2007 to 2017. The JL takes a different bracket version — ask us.

Do the ditch-light brackets have to be fitted?

No. The supplier notes they are used only if you want to add side lights.
