Front shock absorber Ironman 4x4 Nitro Gas, 2" lift — Toyota Land Cruiser KZJ (12696GR)
Lifting a car by 2 inches changes the geometry the suspension works in, and the factory shock stops using the travel it has. 12696GR is a front shock absorber by Ironman 4x4 built for a 2" lift.
Nitro Gas is a nitrogen gas-charged design. Working length is 560–336 mm.
Position
front | Lift
2" (approx. 51 mm) | Series
Nitro Gas | Length
560–336 mm |
Key features
- Working length 560–336 mm — matched to a lifted suspension.
- Nitro Gas construction.
- Sold each — two are needed per axle.
Vehicle fitment
- Toyota Land Cruiser KZJ 70, 73, 77 1990-1996
Technical data
| Part number | 12696GR |
| Manufacturer | Ironman 4x4 |
| Position on the car | front |
| Length max–min | 560 mm – 336 mm |
| Lift | 2" |
| Shock model | Nitro Gas |
| EAN | 9326626013042 |
Fitting and notes
The shock absorber is sold per piece — one axle needs two. The 560–336 mm figure is the extended and compressed length; it is worth comparing it with what is on your car, because one model often came with several suspension variants.
We fit these in our own workshop in Warsaw. While the car is apart we check the springs, bushings and top mounts — replacing shocks alone is rarely the whole job.
Frequently asked questions
Will it fit a car with standard ride height?
This one is matched to a 2" lift. On a standard car it would work on the wrong part of its travel — for factory height, choose the standard version.
How many do I need?
Two per axle. A full set for both axles is four shocks — the rear ones have a different part number.
Why buy it here
Ironman 4x4 is an Australian brand built for vehicles that really work off-road and carry weight. We fit everything we sell in our own workshop in Warsaw, so if you are not sure which version suits your car, write to us — we will work it out with you.
